Fan Guard
fan cover/fan guard
Metal wire fan guards are designed for optimal fan airflow and noise reduction. It is an ideal protection against injuries caused by rotating fan blades, and also keep fans and cables safe from damage, and to ensure safe operation. Wire fan finger guards are ideal for PC system modding enthusiasts.
Specification
Fan guards diameters: 25mm, 30mm, 40mm,50mm, 60mm, 70mm,80mm, 92mm, 120mm, 127mm, 150mm, 160mm, 172mm, 220mm, 254mm, 280mm.
| Fan guard diameter | Rings No. | Ring wire diameter | Rib wire diameter | Screw Holes NO. |
| 25 mm | 2 | 1.4mm | 1.4mm | 2 |
| 30mm, 35mm, 40mm | 2 | 1.6mm | 1.6mm | 4 |
| 50mm | 3 | 1.6mm | 1.6mm | 4 |
| 60mm | 4 | 1.6mm | 1.6mm | 4 |
| 70mm | 5 | 1.6mm | 1.8mm | 4 |
| 80mm | 5 | 1.8mm | 1.8mm | 4 |
| 92mm | 6 | 1.8mm | 1.8mm | 4 |
| 120mm | 8 | 1.8mm | 1.8mm | 4 |
| 127mm, 130mm, 140mm | 8 | 1.8mm | 2.3mm | 4 |
| 150mm | 9 | 2.3mm | 2.3mm | 4 |
| 160mm | 10 | 2.3mm | 2.3mm | 4 |
| 172mm | 11 | 2.3mm | 2.5mm | 4 |
